ANT BY800 Mini Dumper – Compact Power for Construction, Landscaping & Property Maintenance

The ANT BY800 Mini Dumper is a powerful, compact, and highly versatile tracked dumper designed for various applications, including construction, landscaping, acreage, farming, and material handling. Built for efficiency in tight-access areas, this mini dumper combines an impressive 800kg load capacity with hydrostatic drive, hydraulic tipping, and optional self-loading functionality to maximize productivity on site.

With a machine width of only 820–850mm, the ANT BY800 easily accesses narrow pathways, gates, backyards, landscaping projects, and confined construction sites where larger construction equipment cannot operate.

Powered by a reliable 13HP Briggs & Stratton petrol engine with electric start, the BY800 delivers smooth performance, easy operation, and excellent maneuverability across a wide range of terrain and working conditions.

Built for Productivity

The ANT BY800 features a hydraulically operated scissor lift bucket system capable of lifting to 1450mm at the pivot point, making it ideal for:

- loading trailers

- skip bins

- tip trucks

- retaining wall projects

- landscaping materials

- soil and gravel handling

The optional self-loading bucket further improves efficiency by allowing operators to load materials directly without requiring additional equipment.

Ideal Applications

The ANT BY800 Mini Dumper is ideal for:

- construction sites

- landscapers

- retaining wall projects

- backyard access jobs

- acreage properties

- farming applications

- concreting preparation

- trenching projects

- soil and gravel transport

- demolition clean-up

- tight-access material handling

Compact Design – Excellent Access

With an overall width of only 820–850mm, the BY800 is designed specifically for limited-access worksites and confined areas where conventional dumpers or larger tracked dumpers are too large.

The tracked undercarriage provides:

- excellent traction

- low ground pressure

- improved stability

- superior performance on soft or uneven ground

Reliable Hydrostatic Drive System

The ANT BY800 features a quality hydrostatic transmission system with:

- dual variable displacement piston pumps

- hydraulic drive motors

- smooth forward and reverse operation

- easy operator control

The use of high-quality hydraulic components ensures reliable performance and easy operation in demanding conditions.

ANT BY800 Features

- Only 820–850mm wide

- 800kg load capacity

- Hydraulic scissor lift bucket

- Bucket lifting height: 1450mm

- Optional self-loading bucket

- 13HP Briggs & Stratton petrol engine

- Electric and manual start

- Hydrostatic drive system

- USA Hydro-Gear piston pumps

- Hydraulic tipping system

- Compact tracked design

- Easy servicing and maintenance

- Rocking rollers for improved terrain handling

- Crane lifting anchor points

- Excellent maneuverability

- Built for tough working conditions

Optional Post Hole Digger Attachment

Optional hydraulic post hole digger available with:

- 200mm auger

- 300mm auger

Ideal for:

- fencing

- landscaping

- tree planting

- rural property maintenance

ANT BY800 Specifications

General

- Maximum load capacity: 800kg

- Machine weight: 650kg

- Maximum speed: 6.3 km/h

- Dimensions: L2440 × W820 × H1140mm

- Bucket lifting height: 1450mm

- Loader lift capacity: 250kg

Engine

- Briggs & Stratton petrol engine

- 13HP

- 4-stroke

- Electric / manual start

Transmission

- Hydrostatic drive

- 2 × variable displacement piston pumps

- Flow rate: 2 × 32.4L/min

- 2 × orbital hydraulic motors

Hydraulic System

- Hydraulic gear pump

- High flow rate: 22L/min

- Maximum pressure: 150 bar

- Hydraulic tipping bucket

- 2–3 way hydraulic valve system

Tracks

- 180mm track width

- 3 track rollers

- Rocking rollers

- Adjustable track tensioning

Compact Size. Serious Capability.

The ANT BY800 Mini Dumper delivers the ideal combination of:

- compact access,

- high lifting capability,

- smooth hydrostatic drive,

- and heavy-duty material handling performance.

Perfect for contractors, landscapers, builders, farmers, and property owners needing a reliable compact dumper built for demanding Australian working conditions.
