CLOVERAGRI C SERIES MOWER HEAD

C Series Excavator Mower Head, Hydraulic,  Italian quality Casappa Hydraulic Motor, 3-Way Flow Control Valve  - Cloveragri

The C Series Light Flail Mower Heads offer versatile compatibility with various excavators up to 2T, ensuring adaptability for a wide range of applications. They feature advanced hydraulic components, and a robust construction , making them a reliable choice for efficient and precise operations in diverse conditions.

Mower Head for mini excavators of 1.2T - 2T.

Suitable for : brush-cutter for brambles, bushes, ditches, banks, embankments, branches etc.

Suitable for Mini-excavator brands as Haihong, Rhinoceros, Various Chines mini excavators, Caterpillar, Takeuchi, Kubota, JCB, Case, Komatsu, Kubota, Yanmar,  etc.

Requirements for the operating machine:

a) Preferable with double gear pump or piston pump:

    1 for tracking

    1 for operation of the mulcher (C60 pump capacity at least 25 to 30 L/min)

b) The rotation of the knives goes in both directions (a double-acting pedal is necessary).

d) C60SC1 - connecting hitch supplied suit 25mm pins / 85mm pin centres / 91mm between the ears. ( fit most Chinese mini excavators 1.2T to 1.5T, hydraulic cooler required min 25L/min )

 d) C80SC2 - connecting hitch supplied suit 30mm pins / 127mm pin centres / 105mm between the ears.( fit most Chinese mini excavators 1.8 to 2T, Hydraulic cooler required, 40L/min )

d) C80 _connecting hitch supplied suit 30mm pins / 85mm pin centres / 95mm between the ears.( fit Kubota U17-3 mini excavators 1.7T and similar models Hydraulic cooler required, 40L/min )

e) 2 x hydraulic hose designed valve with anti-cavitation. ( 3rd case drain hose not required. )

OVERVIEW

The C Series Light Flail Mower Heads offer remarkable versatility by seamlessly connecting to a wide array of excavators, making them an invaluable tool for a diverse range of applications. Whether you're working with compact or larger excavators, these flail mower heads adapt with ease.

In addition to their adaptability, light flail heads incorporate a host of advanced features designed to enhance their performance and longevity. These features include a pressure relief and anti-cavitation valve, which safeguards the hydraulic system from potential damage, ensuring uninterrupted operation. Furthermore, a 3-way flow control valve with pressure compensation provides you with precise control over the flail head's movements, allowing you to tailor its performance to specific tasks. Hydraulic pipes and connections are protected to prevent wear and tear, extending the flail head's service life even in rugged environments. With an Italian quality CASAPPA hydraulic gear motor capable of handling up to 30 bar of back pressure during discharge, you can confidently tackle challenging tasks.

* Specifications and Prices are subject to change without notice.
